Arctic-Lock
The Arctic-Lock™ Coupler is designed to withstand colder temperatures than the Clear-Lock Coupler. Arctic-Locks are designed with increased impact strength that greatly reduces the risk of cracking or shattering under installation force. The Arctic-Lock Coupler can withstand at least 35% higher impact than standard Clear-Lock Couplers (or 4.7 Jauls impact at -18C). The non-metallic construction provides excellent corrosion resistance in buried or encased applications and also has desirable dielectric properties.
Features
- Designed for cold temperatures
- Ideal for pull boxes, vaults or other limited access areas
- Non-metallic construction provides excellent corrosion resistance
- Simple, one person ‘push-on’ assembly lowers installation costs
- Self-locking ring design assembles in seconds and is re-enterable
- High strength molded plastic body is ideal for buried duct applications
- Pre-lubricated O-ring is water-tight and air-tight
- Suitable for both cable pulling & jetting applications
Technical Specifications
Part # | Description | OD Working Range (in) | Max Pressure (psi) | Pull Out Strength (lb) | Packaging | Amount of Items/Case |
---|---|---|---|---|---|---|
20094317 | 3/4" Arctic-Lock | 1.040 - 1.060 | 250 | 500 | Case | 144 |
20094318 | 1" Arctic-Lock | 1.305 - 1.325 | 250 | 600 | Case | 50 |
20094319 | 1 1/4" Arctic-Lock | 1.650 - 1.670 | 250 | 700 | Case | 50 |
20094320 | 1 1/2" Arctic-Lock | 1.890 - 1.910 | 250 | 800 | Case | 25 |
20094321 | 2" Arctic-Lock | 2.365 - 2.385 | 250 | 2000 | Case | 15 |
