eABF Cables
eABF cables are designed by AFL to offer the most rugged and reliable enterprise-based blown fiber solution in the market today. The cable design combines a light-weight, low-drag jacketing system that allows the cable to be blown long distances. The cable series also features additional attributes that set this product above and beyond traditional blown fiber cables. These enhanced features include mechanical strengthening
that permits the cable to comply with industry-standard premise interconnect specifications. In addition, the eABF cable series feature flame-resistance characteristics which result in stand-alone riser and plenum rated options suitable for routing outside of the micro-duct system. Because of these mechanical, environmental and optical qualifications, eABF cables can also be installed in third-party, flame-rated duct and pathway systems.
Features
- Flame rating options include:
- Plenum OFNP per NFPA 262 OFNP
- Riser OFNR per NFPA NEC 2005 Art 770.51(B)
- Complies with NFPA/NEC build codes for fire resistance
- Can be installed in eABF duct or third-party rated duct systems
- GR-20 Water-blocking reduces risk of moisture migration
- GR-409-CORE compliant
- Complete range of single-mode and multimode fibers supports 10G, 40G and 100G Ethernet architectures
- Aramid-strengthened cable core capable of robust tensile load bearing
- OD compatible with 6 mm ID MicroDucts for higher density fiber pathway solutions
- 96-Fiber count fits into 8.5 mm x 6 mm MicroDuct with up to 2,304 fibers per 24-way FuturePath Duct
Technical Specifications
Select Cable Type
eABF Plenum Cable
eABF Plenum Cable
eABF Riser Cable
| Part # | Description | Nominal OD (in.) | Nominal OD (mm) | Fiber Count | eABF Fiber Type |
|---|---|---|---|---|---|
| 20002973 | MicroCable Plenum ENT-A SM-6 | 0.14 | 3.6 | 6 | SMF |
| 20002974 | MicroCable Plenum ENT-A SM-12 | 0.14 | 3.6 | 12 | SMF |
| 20002975 | MicroCable Plenum ENT-A SM-24 | 0.14 | 3.6 | 24 | SMF |
| 20001451 | MicroCable Plenum ENT-A SM-48 | 0.15 | 3.8 | 48 | SMF |
| 20003337 | MicroCable Plenum ENT-A SM-72 | 0.18 | 4.5 | 72 | SMF |
| 20003631 | MicroCable Plenum ENT-A SM-96 | 0.18 | 4.5 | 96 | SMF |
| 20002976 | MicroCable Plenum ENT-A OM1-6 | 0.14 | 3.6 | 6 | OM1 |
| 20002977 | MicroCable Plenum ENT-A OM1-12 | 0.14 | 3.6 | 12 | OM1 |
| 20002978 | MicroCable Plenum ENT-A OM1-24 | 0.14 | 3.6 | 24 | OM1 |
| 20002979 | MicroCable Plenum ENT-A OM1-48 | 0.15 | 3.8 | 48 | OM1 |
| 20003338 | MicroCable Plenum ENT-A OM1-72 | 0.18 | 4.5 | 72 | OM1 |
| 20002980 | MicroCable Plenum ENT-A OM2-6 | 0.14 | 3.6 | 6 | OM2 |
| 20002981 | MicroCable Plenum ENT-A OM2-12 | 0.14 | 3.6 | 12 | OM2 |
| 20002982 | MicroCable Plenum ENT-A OM2-24 | 0.14 | 3.6 | 24 | OM2 |
| 20002983 | MicroCable Plenum ENT-A OM2-48 | 0.15 | 3.8 | 48 | OM2 |
| 20003339 | MicroCable Plenum ENT-A OM2-72 | 0.18 | 4.5 | 72 | OM2 |
| 20002984 | MicroCable Plenum ENT-A OM3-6 | 0.14 | 3.6 | 6 | OM3 |
| 20002985 | MicroCable Plenum ENT-A OM3-12 | 0.14 | 3.6 | 12 | OM3 |
| 20002986 | MicroCable Plenum ENT-A OM3-24 | 0.14 | 3.6 | 24 | OM3 |
| 20002987 | MicroCable Plenum ENT-A OM3-48 | 0.15 | 3.8 | 48 | OM3 |
| 20003340 | MicroCable Plenum ENT-A OM3-72 | 0.18 | 4.5 | 72 | OM3 |
| 20002988 | MicroCable Plenum ENT-A OM4-6 | 0.14 | 3.6 | 6 | OM4 |
| 20002989 | MicroCable Plenum ENT-A OM4-12 | 0.14 | 3.6 | 12 | OM4 |
| 20002990 | MicroCable Plenum ENT-A OM4-24 | 0.14 | 3.6 | 24 | OM4 |
